SIMDOS®10 membrane dosing pump FEM 1.10 KT.18 S2
$3,696.11
-Application: Metering liquids
-Flow rate from 0.03 up to 100 ml/min / Pressure head 60 mWg, suction head 2 mWg and 3 mWg respectively
-Pump heads available in your choice of PP, PVDF or PTFE-diaphragms available in PTFE, valves in FFKM
-Flow rate can either be set manually (Version S) or both manually and via an external control device as well as with interface RC 232 (Version RCP)
-Additional safety diaphragm for maximum security
-Easy exchange of the transfer diaphragm by activating the maintenance command in the operating program
Advantages:
-Intuitive operation, easy calibration
-Adjustable to liquid characteristics
-Self-priming and dry-running
-Spray water protected IP 65
-Small size
Specifications
Pressure: 6 bar
Allowed ambient temperature: +5 ... +40 °C
Allowed liquid temperature: +5 ... +80 °C
Dimensions (WxDxH): 93 x 150 x 144 mm
Pump head: optional PP, PVDF or PTFE
Diaphragm: PTFE
Valves: FFKM
Power supply: 100-240 V, 50-60 Hz
Weight: 0.9 kg
