The MOTIC BA310E Binocular Microscope is a high-performance upright microscope designed for life sciences, universities, clinics, and routine laboratory applications. Built with Infinity Optics (CCIS), this model ensures precision, durability, and comfort for extended daily use.
Product Features
- Optics: Infinity Optics (CCIS)
- Observation Tube: Siedentopf type, binocular, 30° phototube, F.N. 20
- Interpupillary Distance: 48–75 mm
- Eyepieces: N-WF 10x/20 mm, high-eyepoint with dioptre adjustment and rubber eyecups
- Nosepiece: Reversed quintuple revolving
- Objectives: CCIS EC Plan 4x, 10x, 40x-S, 100x-S (Oil)
- Stage: Built-in low-position coaxial rackless mechanical stage (right-hand control)
- Condenser: Focusable Abbe condenser N.A. 0.90/1.25 with iris diaphragm and slot
- Illumination: Koehler 3 W LED with intensity control (universal power supply 100–240 V, CE)
- Optional Illumination: 6 V / 30 W HAL
Scope of Supply
- Immersion oil (5 ml)
- Power cord
- Allen hexagonal key
- Thumb screw
- Vinyl dust cover
Optional Accessories
- Phase-contrast (10x/20x/40x/100x) for slider or turret condenser
- Darkfield (10x–40x) for slider or turret condenser
- Polarization kit
Benefits
- Reliable performance for daily laboratory use
- High-quality CCIS Infinity Optics for accurate imaging
- Ergonomic design with comfortable viewing angles
- Versatile illumination options for different applications
- Robust construction for long-term use in clinical, research, and academic environments
Why Choose MOTIC BA310E?
The MOTIC BA310E Binocular Microscope combines high optical quality, ergonomic design, and robust engineering. Ideal for routine and advanced lab work, it ensures precision and reliability in microscopy applications across clinical, research, and educational settings.
