The Mark-10 M2-500 Digital Force Gauge is designed for basic tension and compression force testing applications up to 100 lb (500 N). Its compact and ergonomic design provides accurate and flexible measurement solutions in both laboratory and production environments.
Product Features
- Basic solution for simple force measurement requirements
- Calculates peak tension and compression values
- Three selectable units of measurement
- Ultra-compact, ergonomic housing
- Configurable default measurement unit and mode
- 500 Hz sampling rate for precise measurements
- Large, backlit graphic display with auto-dimming
- Reversible housing for alternate load cell orientation
Whats Included
- One 9 V battery
Benefits
- Accurate peak tension and compression measurements with ±0.5% accuracy
- Ergonomic and reversible design allows handheld use or fixture mounting
- Rugged construction suitable for laboratory and production environments
- Compatible with Mark-10 test stands and grips for expanded testing capabilities
Why Choose Mark-10 M2-500 Digital Force Gauge?
This gauge provides a reliable, compact, and flexible solution for basic force measurement applications, ensuring accurate and efficient testing in various environments.
