The 722C12TCE2FA General Purpose Absolute Baratron® Capacitance Manometer features 100 Torr full scale pressure measurement with ±0.5% of reading accuracy and a female 8 VCR type fitting. Electrical connections for the +13 to +32 VDC power requirements and 0-10 VDC proportional analog output are made with a 9-pin Type "D" electrical connector. It features a flexible design making it an ideal solution for retrofit applications as well as new equipment designs. Robust sensor construction provides high overpressure tolerances, reducing errors caused by occasional line pressure spikes. All sensor wetted surfaces are made from Inconel® to ensure maximum compatibility with many process gases. Sophisticated technology and strict process controls ensure clean, smooth finishes (<10 Ra) on all wetted surfaces. Signal conditioning circuitry is assembled using the latest techniques in surface mount technology. All transducers are backed with a full two-year warranty.
Vacuum Pressure Transducer, Absolute, 100 Torr, 0-10 VDC, 8 VCR-F, DB9
The 722C12TCE2FA General Purpose Absolute Baratron® Capacitance Manometer features 100 Torr full scale pressure measurement with ±0.5% of reading accuracy and a female 8 VCR type fitting. Electrical connections for the +13 to +32 VDC power requirements and 0-10 VDC proportional analog output are made with a 9-pin Type "D" electrical connector. It features a flexible design making it an ideal solution for retrofit applications as well as new equipment designs. Robust sensor construction provides high overpressure tolerances, reducing errors caused by occasional line pressure spikes. All sensor wetted surfaces are made from Inconel® to ensure maximum compatibility with many process gases. Sophisticated technology and strict process controls ensure clean, smooth finishes (<10 Ra) on all wetted surfaces. Signal conditioning circuitry is assembled using the latest techniques in surface mount technology. All transducers are backed with a full two-year warranty.
